Product name

Y5528 BLACK

Y5528 BLACK

Product features

Y5528 black MONEY COUNTER Name:Bill Counter Color:Black Size:310*280*190mm N.W:6KG Function:sheets counting+value counting


Product description

Y5528 BLACK


Y5528 black  MONEY COUNTER



Name:Bill Counter

Color:Black

Size:310*280*190mm

N.W:6KG

Function:sheets counting+value counting

Certification:ISO, CE, FCC, CCC

Hopper/Stacker Capacity:≥130pcs

Counting Speed:≥1000pcs/min

Size of countable note:50*110-90*180mm

Display:TFT



Product Description

FEATURES



1. Full Intelligent Mode: Automatic Start, Stop and Clear

2. Multiple Anti-fake Detection: UV(ultraviolet), MG(magnetic), IR(infrared), MT(Metal thread) and 3D(Sizes)



3. Alarm Mechanism: When fake cashes go through it, it will alarm promptly and error code will show on display.



4.Mix Value Counting Function: It will show total amount and total pieces for each denomination.



5. Automatic Half-note, Chained-note, Double-note Detection



6. Simulation Human Voice Broadcast Function



7. Color Sensor Detection + 3D Detection



8. OEM&ODM are welcomed.



SPECIFICATIONS

Power supply



AC220V/50Hz AC110V/60Hz

Power consumption

<75W;   Ready time:<1min

Counting speed

>1000pcs/min

Applicable paper

50(W)*110(L)-90 (W)*180 (L) mm,0.075 (T)~0.15(T) mm

Hopper and Stacker capacity

>130pcs

Display range

6 digits Counting Display,  6 digits Batch Display

Extenal size

(L)360mm X (W)317mm X (H)220mm

Total weight

7.5KG

1564641273(1)

1564641293(1) 1564641330(1)

Detailed Images

1564641443(1)



TFT(Thin Film Transistor) display can be customized according to your requirements. Several function buttons can meet all of your operating requirements.



1564641463(1)



Multiple anti-fake detection (IR, UV, MG, MT) take strict control of cashes, available for detecting most currencies worldwide.

1564641484(1)

One button for starting and stopping. Heat dissipation design helps it to work longer for you.


HTB1B_IjXK3tHKVjSZSgq6x4QFXahHTB1T3beMSzqK1RjSZPxq6A4tVXa0Y5528 2Y5528 3Y5528 4Y5528 5Y5528 6Y5528-New-Product-2019-Portable-Financial-EquipmentY5528-New-Product-2019-Portable-Financial-Equipmentddddddd
